200W Railway DC-DC Converter – DDC200R-110-CMC
The PROXIMWORLD’S DDC50R Railways Series DC-DC Converter features wide input range, high density power in less foot-prints, Designed for Critical applications like EV, Telecom, Railways Automation use. With peak 52W power, These DC-DC converter are compact and designed for High-end transport application.
Technical Description:
- Input voltage range DC110V (40-160V)
- Output voltage: DC +5V/12V/19V/24V/48V
- Total Power: 200W Peak 220W*
- Isolation: Between Input and output DC1500*
- Operation: Work in continuous mode.
- MTBF: 100k hrs min. MIL-HDBK-217F(25℃)
- Efficiency: >91% typical during lab test.*
- Working temperature: -30°C ~ 71°C.
- Product size 180*90*40mm, Approx weight 250gr.
- Compliance to EN61000, IEC62368 and EN50155.
- Protections: DC high-Low, Short circuit, Overload inbuilt.
- Comply Environment: EN50155 Class A meets transport vibrations.
- Cooling: Convection, Fan cooling may require if 24×7 application
- Use: Railway, Transport, Metro rail, High speed railway application.
- Converter all side sealed IP65 with Aluminium Mounting Plate.
- High grade 9.50mm pitch terminals for IN/OUT connections.
Description
200W Railway DC-DC Converter
DDC200R-110-**-CMC
High-Power & Reliable DC-DC Power Conversion Solution for Railway,
Metro, Transportation, EV & Telecom Applications
The PROXIMWORLD DDC200R Railway Series DC-DC Converter is a high-power, high-density power conversion solution designed for critical railway and transportation applications. Its rugged construction, wide input range and compact design make it suitable for demanding operating environments. With a rated power of 200W and up to 220W peak power, the DDC200R series supports multiple output voltage configurations including +5V, +12V, +19V, +24V and +48V. This makes it suitable for a wide range of railway electronics, transportation systems and industrial equipment.
Technical Specifications
INPUT VOLTAGE
DC 110V
Input Range: 40–160VDC
OUTPUT VOLTAGE
+5V / +12V / +19V
+24V / +48V configurations
TOTAL POWER
200W
Peak Power: 220W
ISOLATION
DC 1500V
Between input and output
OPERATING MODE
Continuous Operation
Designed for continuous-duty applications
MTBF
100K Hours Minimum
MIL-HDBK-217F @ 25°C
EFFICIENCY
>91%
Typical during lab testing
OPERATING TEMPERATURE
-30°C to +71°C
Wide operating temperature range
PRODUCT SIZE
180 × 90 × 40 mm
Rugged mounting design
APPROX. WEIGHT
250 g
Approximate unit weight
Railway & Transportation Applications
The DDC200R series is designed for high-end transportation applications where high power density, stable operation and robust mechanical construction are required.
Railway Systems
Railway Automation
Metro Rail
Transportation
EV Applications
Telecom
Protection & Reliability
✓ DC High / Low Protection
Built-in input voltage protection
Built-in input voltage protection
✓ Short Circuit Protection
Protection against short-circuit conditions
Protection against short-circuit conditions
✓ Overload Protection
Built-in overload protection
Built-in overload protection
✓ IP65 Sealed Converter
Enhanced environmental protection
Enhanced environmental protection
Railway Standards & Construction
The DDC200R series is designed for transportation applications and complies with EN61000, IEC62368 and EN50155 requirements. The design supports demanding railway environments
and transportation vibration conditions.
The converter features a sealed IP65 enclosure with an aluminium mounting plate for robust installation. High-grade 9.50 mm pitch terminals provide secure input and output connections.
Cooling & Installation
The converter uses convection cooling under normal operating conditions. For 24×7 applications or installations with higher thermal loads, fan cooling may be required depending on the application and installation environment.
Key Features
200W Rated Power
Up to 220W peak power for high-demand applications.
Multi-Output
Supports +5V, +12V, +19V, +24V and +48V configurations.
High Efficiency
Typical efficiency greater than 91%.
Rugged Construction
Aluminium mounting plate for demanding railway environments.
Customization Available
Specifications can be changed, customized or configured according to
specific application requirements and buyer requests. Contact
PROXIMWORLD for application-specific technical support and configuration.
