980W Railway DC-DC Converter – DDC1000R-110-CMC
The PROXIMWORLD’S DDC50R Railways Series DC-DC Converter features wide input range, high density power in less foot-prints, Designed for Critical applications like EV, Telecom, Railways Automation use. With peak 52W power, These DC-DC converter are compact and designed for High-end transport application.
Technical Description:
- Input voltage range DC110V (40-160V)
- Output voltage: DC +5V/12V/19V/24V/48V
- Total Power: 980W Peak1100W*
- Isolation: Between Input and output DC1500*
- Operation: Work in continuous mode.
- MTBF: 100k hrs min. MIL-HDBK-217F(25℃)
- Efficiency: >91% typical during lab test.*
- Working temperature: -30°C ~ 71°C.
- Product size 240*190*85mm, Approx weight 2Kgr.
- Compliance to EN61000, IEC62368 and EN50155.
- Protections: DC high-Low, Short circuit, Overload inbuilt.
- Comply Environment: EN50155 Class A meets transport vibrations.
- Cooling: Convection, Fan cooling may require if 24×7 application
- Use: Railway, Transport, Metro rail, High speed railway application.
- Converter all side sealed IP65 with Aluminium Mounting Plate.
- High grade 9.50mm pitch terminals for IN/OUT connections.
Description
980W Railway DC-DC Converter
DDC1000R-110-**-CMC
High-Power & Reliable DC-DC Power Conversion Solution for Railway,
Metro Rail, Transportation, EV & Telecom Applications
The PROXIMWORLD DDC1000R Railway Series DC-DC Converter is a high-power, high-density DC power conversion solution designed for demanding railway and transportation applications. Its rugged construction, wide input range and efficient thermal design make it suitable for critical systems where reliable and stable power conversion is essential.
With a rated power of 980W and up to 1000W peak power, the converter supports multiple output voltage configurations including +5V, +12V, +19V, +24V and +48V.
It is designed for high-demand railway electronics, railway automation, metro rail, transportation and related applications.
Technical Specifications
INPUT VOLTAGE
DC 110V
Input Range: 40–160VDC
OUTPUT VOLTAGE
+5V / +12V / +19V
+24V / +48V configurations
TOTAL POWER
980W
Peak Power: 1000W
ISOLATION
DC 1500V
Between input and output
OPERATING MODE
Continuous Operation
Designed for continuous-duty applications
MTBF
100K Hours Minimum
MIL-HDBK-217F @ 25°C
EFFICIENCY
>91%
Typical during lab testing
OPERATING TEMPERATURE
-30°C to +71°C
Wide operating temperature range
PRODUCT SIZE
240 × 190 × 85 mm
High-power rugged construction
APPROX. WEIGHT
2 kg
Approximate unit weight
Railway & Transportation Applications
The DDC1000R series is designed for high-end transportation applications
requiring high power output, reliable operation and rugged construction.
Its wide input range and multiple output options provide flexibility
for demanding railway power systems.
Railway Systems
Railway Automation
Metro Rail
Transportation
EV Applications
Telecom
Protection & Reliability
✓ DC High / Low Protection
Built-in input voltage protection
Built-in input voltage protection
✓ Short Circuit Protection
Protection against short-circuit conditions
Protection against short-circuit conditions
✓ Overload Protection
Built-in overload protection
Built-in overload protection
✓ IP65 Sealed Converter
Enhanced environmental protection
Enhanced environmental protection
Railway Standards & Construction
The DDC1000R series is designed for transportation applications and
complies with EN61000, IEC62368 and EN50155
requirements. The design supports demanding railway environments
and transportation vibration conditions.
The converter features a sealed IP65 enclosure with
an aluminium mounting plate for robust installation.
High-grade 9.50 mm pitch terminals provide secure
input and output connections.
Cooling & Installation
The converter uses convection cooling under normal
operating conditions. For 24×7 applications or
installations with higher thermal loads, fan cooling may be required
depending on the application and installation environment.
Key Features
980W Rated Power
Up to 1000W peak power for high-demand applications.
Multi-Output
Supports +5V, +12V, +19V, +24V and +48V configurations.
High Efficiency
Typical efficiency greater than 91%.
Rugged Construction
Designed for demanding railway and transportation environments.
Customization Available
Specifications can be changed, customized or configured according to
specific application requirements and buyer requests. Contact
PROXIMWORLD for application-specific technical support and configuration.
