16W High Voltage DC-DC Converter – DDC15SP-150024-M
- 16W High Voltage DC-DC Converter
- Wide DC input range: 200–1500V
- 24V DC output with 800mA peak, 1A maximum
- 2500VDC / 4000VAC isolation
- Typical efficiency above 89%
- Continuous operation design
- Operating temperature: -40°C to +71°C
- Built-in DC overload and over-voltage protection
- Sealed epoxy aluminium case for waterproof protection
- PCB mount with 5.08 pitch input and output terminals
- Ideal for solar power monitoring, solar inverters and solar power plants
Description
HIGH VOLTAGE DC-DC CONVERTER
16W High Voltage DC-DC Converter
The PROXIMWORLD DDC15SP Series DDC15SP-150024-M is a compact high-voltage DC-DC converter designed for demanding applications such as solar power monitoring, SCADA systems, solar inverters and solar power plants. It converts a wide DC input range into a regulated 24V DC output.
16W Power
200–1500V DC Input
24V DC Output
2500VDC / 4000VAC Isolation
PCB Mount
PRODUCT OVERVIEW
Compact High-Voltage DC-DC Power Conversion
The PROXIMWORLD DDC15SP Series
features a wide DC input range of 200V to 1500V and is designed for high-end applications including solar power monitoring, SCADA systems, solar inverters and solar power plants.
The DDC15SP-150024-M provides a regulated +24V DC output with 800mA peak output capability and up to 1A as specified. The converter incorporates high-voltage isolation of 2500VDC / 4000VAC for demanding power conversion applications.
Its sealed epoxy aluminium case provides waterproof protection, while the compact PCB-mount design with 5.08 pitch terminals allows convenient integration into industrial and renewable energy equipment.
KEY FEATURES
Engineered for Reliable High-Voltage Operation
01
Wide Input Voltage Range
Supports a wide 200V to 1500V DC input range for high-voltage solar and industrial power systems.
02
Regulated 24V Output
Provides a stable +24V DC output with 800mA peak and 1A output capability as specified.
03
High-Voltage Isolation
Provides 2500VDC / 4000VAC isolation for applications requiring separation between high-voltage input and output.
04
High Efficiency
Typical efficiency is specified above 89% during
laboratory testing conditions.
05
Continuous Operation
Designed for continuous-mode operation in demanding solar and industrial power applications.
06
Wide Temperature Range
Designed for operation from -40°C to +71°C under specified ambient operating conditions.
TECHNICAL DATA
Technical Specifications
INDUSTRIAL CONSTRUCTION
Sealed Design & Built-In Protection
01
Sealed Epoxy Aluminium Case
The converter is enclosed in a sealed epoxy aluminium
case designed to provide waterproof protection.
02
Over-Voltage Protection
Built-in over-voltage protection helps safeguard the
converter against abnormal voltage conditions.
03
DC Overload Protection
Integrated DC overload protection helps support
dependable operation under abnormal load conditions.
04
Natural Air Cooling
Convection and natural-air cooling provide thermal
management without requiring forced-air cooling.
APPLICATION AREAS
Applications
Designed for high-voltage DC conversion and auxiliary
power requirements in renewable energy and industrial systems.
DDC15SP-150024-M
Compact High-Voltage DC-DC Conversion for Solar Systems
With a 200–1500V DC input range, 24V DC output, high-voltage isolation, greater than 89% typical efficiency and a sealed
industrial enclosure, the DDC15SP-150024-M is designed for demanding solar and high-voltage DC applications.
Specifications can be customized as per buyer requirements.
